Part-turn Electrical Actuator
Designed for applications of 1/4 turn (90º) and
reversible, ideal for the electric automation of ball
valves and butterfly valves.
Different sizes according to the operation torque: 100,
۱۶۰, ۲۴۰, ۳۵۰, ۵۰۰ … ۲۰۰۰ Nm.
Standard voltage is 3 x 400 VAC:
Other voltage on request:
۲۴VDC : References GE-010 / 015 / 025
۱۱۰VAC : All References
۲۲۰VAC: All References
–
| WIRING DIAGRAMS | |
| Close Limit Switch (250 VAC 10A) | CLS: |
| Open Limit Switch (250 VAC 10A) | OLS: |
| Aux. Close Limit Switch (250 VAC 10A) | ACLS: |
| Aux. Open Limit Switch (250 VAC 10A) | AOLS: |
–
Options available: |
ADVANTAGES: |
| positioner, local control unit, LCD screen and infrared. | Housing manufactured of anodized aluminium die casting. |
| High corrosion protection with Epoxy coating. Valve coupling flange according to the standard ISO 5211. | |
| Protection IP 67 | |
| Mechanical Position Indicator. |
